- Data Link
Diplexers
for
UAV Operations
| Micro-Tronics offers data link diplexers for UAV operations. Airborne diplexers are available with power handling of up to 75 Watts. Ground based diplexers are available with power handling of up to 500 Watts. The diplexers listed below are representative of the types designed and manufactured by Micro-Tronics. If you have specific requirements, please submit your specifications. Submit Request for Quote | ||||||
| Passbands (MHz) | Model Number | VSWR | Insertion Loss
(dB) |
Operating Power (W CW) |
Altitude (ft ASL) |
Size (inches) |
|---|---|---|---|---|---|---|
| 4400 to 4625 4775 to 5000 |
DIP50519 | 1.3:1 | 1.2 | 40 | 65000 | 6.09 x 1.48 x .93 |
| 4400 to 4625 4775 to 5000 |
DIP50520 | 1.3:1 | 1.0 | 10 | 20000 | 4.00 x 1.50 x .60 |
